Stainless steel honeycomb panel refers to the use of stainless steel sheet material grade 201, 304, or 316 as the panel substrate, the core material is aluminum honeycomb core, and the back panel can be stainless steel sheet, aluminum sheet, or galvanized sheet, which is compounded by special adhesive finished plate.
Benefits of Stainless Steel Honeycomb Panel
Various shapes and strong decoration
The stainless steel honeycomb panel has its special metallic luster. It can use electroplating copper plating technology or PVD vacuum ion coating technology to color the surface of the stainless steel panel. Rich in color, it can do surface treatment such as hairline, mirroring, sandblasting, random patterning, etching, and other effects on the panel, which is extremely decorative.
Environmental protection, health, and safety
All made of metal materials, the material itself has stable performance, will not release polluting harmful substances, and can be completely recycled, in line with green environmental protection standards. Some plates are made of food-grade stainless steel such as 304 or 316, which is healthier and safer.
Superior function and durability
Stable material function, lightweight, high flatness, large plate width, high strength, strong impact resistance, good waterproof, sound insulation, thermal insulation function, good wind pressure resistance, and good weather resistance and self-cleaning. It is a non-combustible material with excellent fire resistance, and the fire resistance level can reach the highest level of A1.
Convenient construction and easy installation
It can be installed in any order, and each wall panel can be disassembled and replaced individually, which improves the flexibility of installation and maintenance and reduces costs. Because of its light weight, easy disassembly and assembly, and no damage to the board, it is convenient to transport and can be transported to different places for repeated use.
-
![Stainless Steel Wall Panels Use in Factories Or Other Places]()
Stainless Steel Wall Panels Use in Factories Or Other PlacesStainless steel honeycomb wall panel is a new type of building decoration material. It is composed of stainless steel panel and honeycomb core material, with high strength, light weight, fireproof, moisture-proof, corrosion-resistant andread more -
![Stainless Steel Honeycomb Panel for Outdoor Wall]()
Stainless Steel Honeycomb Panel for Outdoor WallOur Stainless Steel Honeycomb Panel for outdoor walls is a high-quality, durable material designed for exterior cladding. Characterized by its unique honeycomb structure, this panel offers excellent insulation, lightweight properties, andread more -
![Stainless Steel Honeycomb Panel for Car]()
Stainless Steel Honeycomb Panel for CarThe stainless steel honeycomb panel for cars offers a superior blend of strength, lightweight design, and functional versatility. Crafted from high-quality stainless steel, these panels feature a robust honeycomb structure that providesread more -
![Stainless Steel Honeycomb Panels for Chemical Industry]()
Stainless Steel Honeycomb Panels for Chemical IndustryStainless Steel Honeycomb Panels for the Chemical Industry are advanced composite materials designed to offer exceptional strength, durability, and corrosion resistance. These panels consist of a stainless steel face sheet bonded to aread more
Why Choose us
Quality Assurance
The company's products have passed IS09001, CE and SGS certification. The products are sold well in China and are continuously exported to South Korea, Thailand, Russia, Spain, India, Turkey, Dubai, UAE, Nepal and other countries.
Experienced team
Our team comprises professional and experienced individuals who possess the necessary skills to handle and deliver your project with a top-rated result.
Customer satisfaction
We place customer satisfaction at the core of our operations. We aim to deliver services that exceed our customer's expectations and earn their trust.
Mirror stainless steel honeycomb panel
After the stainless steel surface is processed by polishing and grinding equipment, the smooth and reflective surface effect (also called mirror surface) is obtained.
Brushed stainless steel honeycomb panel
After the stainless steel surface is processed by mechanical friction, a straight skin texture (also called frosted) is obtained, including hairline,and pattern, water ripple, etc.
Sandblasted stainless steel honeycomb panel
After the stainless steel surface is processed by high-speed jetting, then will get a sand surface texture.
Etched stainless steel honeycomb panel
After the stainless steel surface is processed by chemical reagents, the designed patterns and characters are obtained.
Installation method of stainless steel honeycomb panel
Lifting ear type
The lifting ear and the honeycomb panel are separated. The lifting ear is connected to the glue seam position of the honeycomb panel after being processed separately. The suitable width of the glue seam is ≥12mm. This installation method makes the processing simple and the installation convenient.
Flanging
It is a flange for installation when processing stainless steel honeycomb panels. The installation only needs to place the connection with the keel and the glue seam. The suitable glue seam width is ≥ 10mm. This method is easy to install, but the processing is slightly complicated, and it is not suitable for Shaped curtain wall panels.
Hook-up hoisting
It is mainly used in ceilings with infinite height difference and no special shape. After installation, the ceiling is stable as a whole. This method is not recommended for honeycomb panels with larger spokes and thinner panels.
Z-shaped pendant hoisting
It is widely used, easy to process, simple to install, and can be repaired by someone after hoisting. It is suitable for ceiling installation of any shape.
U-shaped pendant type
Use the method of hanging directly to the keel below, and then fixing it with the keel at the reach of the hand. This hoisting method solves the problem of the ordinary Z-shaped pendant type, which has a wide spoke and a low keel, which cannot be installed by people.
Construction Technology Of Stainless Steel Honeycomb Panel
Construction preparation
① According to the design requirements of existing texts, drawings, etc., the processing, compounding, and detailed design of stainless steel honeycomb panels are carried out.
② Clean up the site to ensure a good and safe construction environment. At the same time, confirm whether the pipeline reservation of water, electricity, and equipment has been basically completed and meets the design requirements.
③ Prepare the required plates, accessories, installation tools, etc., and check whether they are complete and flawless.
Measure and put the line
Due to the large allowable error in civil construction, and the high precision required for stainless steel honeycomb panel engineering, it is necessary to re-measure according to the reference axis and benchmarking point. At the same time, according to the design drawings, the level line pops up on the wall column surface, and the ceiling level line and the keel position line pop up at the bottom of the floor.
Install the structural skeleton
Drill holes at the position of the boom, and after determining the elevation of the lower end of the boom, install the pre-fabricated boom. The boom installation is fixed on the ceiling floor with Pa expansion bolts, and then the main keel is connected with the hanging bars with the hanging pieces. After that, the installation and fixing of the side keel, the secondary keel, etc. are completed in turn.
Install stainless steel honeycomb panels
The angle steel hanger is connected with the secondary keel with bolts, and the stainless steel honeycomb panel is matched with the keel hanger and then connected with the angle steel hanger bolt. When installing, a reference line should be drawn in the middle position perpendicular to the direction of the secondary keel, and the stainless steel honeycomb panels can be aligned and installed.
Leveling acceptance
Panel leveling is the last key process of ceiling installation. Its construction quality determines the appearance of the entire ceiling. It is necessary to carefully level the panel and the panel. After leveling, tighten all connections until acceptance is reached. Require.
Cleaning
After the installation is completed, the work platform should be removed and the construction site should be cleaned.
Many different industries use stainless steel honeycomb panels even outside of construction such as aviation and transportation. For example, honeycomb structures are used for aircraft wings, train bulkheads, and floors, the exteriors of cars, and car doors.
Honeycomb shapes are used extensively for construction such as the exterior cladding of buildings, but stainless steel honeycomb panels can also offer structural strength to other building areas. Curtain walls, louvers, and roofs for buildings are other places stainless steel honeycomb panels are found in addition to exterior facades.
Interior decoration uses stainless steel honeycomb panels as screen dividers and soundproof panels. Due to its lightweight nature, stainless steel honeycomb panels are incorporated into mobile homes or other structures that are temporary or extra buildings, (“portables”) for schools, churches, and other organizations.
5 Uses of Stainless Steel Honeycomb Panels
Stainless steel honeycomb panel is a strong and light weight composite structure made by integrating two different components of the modern composites. It plays an important role across industries. There are various types of materials used in creating stainless steel honeycomb panels.
A honeycomb can be constituted with different types of constituents like non-metallic, light weight panels and more. The most common material where you can see the example of using stainless steel honeycomb panels is non-metallic and light weight i.E. Woven fiberglass cloth. Apart from this there are several applications and uses of stainless steel honeycomb panels:
Industries such as military applications, rotor crafts, commercial and business jets, some high end boats and high end automotive applications use stainless steel honeycomb panels.
The main objective of panels for using in industry is to minimize the weight and maximize the strength and stiffness. The panel has fire resistance capabilities with faa (federal aviation administration) regulations to hold back fires on aircraft.
Another use of stainless steel honeycomb panels in aircraft flights is for controlling the surfaces such as spoiler, flap, aileron and rudder.
Stainless steel honeycomb panels are also used for structure designing in aircraft.
Stainless steel honeycomb panel is also used in building and construction projects. It appears in industrial and office building, weather renovation and in private houses.
The characteristics of stainless steel honeycomb panels that have resulted in the rapid growth of these elements, particularly in construction industry, are as follows:
• Thermal resistance: When a system is integrated with stainless steel honeycomb panels, it minimizes the thermal bridge through the joints.
• Mechanical properties: The space between the supports can be depending on the panel used and the normal application of panel, which is approximately 3m-5m.
• Fire behavior: There are many different types of fire behavior in sandwich panels that depends on the metal thickness, the foam and the coating. The users can choose different sandwich panel that depends on their requirement.
Stainless steel honeycomb panels having the high flexural rigidity and strength with the low weight. The design and the result of the stainless steel honeycomb panel are verified with the experiments.
Our Factory
Kangbeier Technology Innovation (Shandong) Co., Ltd. was established in 2006. After nearly 20 years of development, it has gradually established five branches, including Shandong Liujun Decoration Materials Co., Ltd., Shandong Liujun International Trade Co., Ltd. (Export Company), Shanghai Kangbeier New Materials Technology Co., Ltd., and Guangdong Alu minum New Materials Co., Ltd. It is a comprehensive company integrating scientific re search, production, sales, international trade and services.
The company is headquartered in Shanghai, China. with two production bases. The first is located in Linyi, Shandong, and the second is located in Guangzhou, China. The main products are Aluminum honeycomb composite materials, including aluminum honeycomb ceiling and wall systems, aluminum honeycomb partition systems, aluminum honeycomb furniture panel systems, and aluminum honeycomb ship RV systems. It is committed to providing high-quality products and services to global users.
Asked Questions
Q: What is stainless steel honeycomb panel?
A: Stainless steel honeycomb panel is composed of metal panels, back panels, and honeycomb -shaped core materials with a combination. According to the different panel materials, it can usually be divided into aluminum honeycomb boards and stainless steel honeycomb boards.
Q: Is stainless steel honeycomb panel durable?
A: The hexagonal inner cellular structure and superior raw material of eltete stainless steel honeycomb panel, provide extraordinary compression strength and rigidity, which can withstand impact and excessive loads – perfect for “heavy-duty packaging”. It is also a great sustainable alternative to EPS packaging.
Q: What are stainless steel honeycomb panels used for?
A: Honeycomb composites are used widely in many industries, from aerospace industries, automotive and furniture to packaging and logistics. The material takes its name from its visual resemblance to a bee's honeycomb – a hexagonal sheet structure.
Q: Is stainless steel honeycomb panel strong?
A: There are several advantages of honeycomb panels, but the primary benefit is the panels' strength. Hexagonal shapes in nature, such as honeycombs, create structures that distribute force evenly, making the structures of the hexagonal shape mutually supportive.
Q: How is steel honeycomb made?
A: In the present invention, stainless steel honeycomb panel is produced by coinciding sheet of solder type lead on one side of stainless steel panel with flux on both sides, placing, honeycomb between stainless steel panels wherein lead coincided side is to the inner side, and heating both sides of stainless steel panel ...
Q: What is the thermal conductivity of a stainless steel honeycomb panel?
A: Panel, the theoretical effective thermal conduction of the stainless steel honeycomb panel was found, ranging from 1.03 to 1.07 Q/m/K for a heat input of 2.5 W to 11.8 W.
Q: What is the density of a stainless steel honeycomb panel?
A: Honeycomb cores can be produced with densities of 60 – 120 kg/m³. Our standard honeycomb core has a density of 80-90 kg/m³ and has a compressive strength of 1. 2 MPa and a compressive modulus of 40 MPa.
Q: What is the density of stainless steel honeycomb panel?
A: Cell size • Alloy and foil gauge (aluminum honeycomb only) • Density Cell sizes range from 1/16" to 1", with 1/8", 3/16", 1/4", and 3/8" being the most common. Honeycomb densi- ties range from 1.0 lb/ft3 to 55 lb/ft3.
Q: How are stainless steel honeycomb panels made?
A: Foil is passed through a printer for adhesive lines to be printed. Once the lines are printed, the foil is cut to size and stacked into piles using our stacking machine. These stacked sheets are pressed using a heated press to allow the adhesive to cure and bond the sheets of foil together to form a block of honeycomb.
Q: How do you clean stainless steel honeycomb panel?
A: The typical cleaning procedure for aluminum (AMS 5052) honeycomb cores at this manufacturer is manual cleaning using acetone. The cleaned cores are then assembled into composite structures using Aluminum 2024-T3 Unclad (AMS 4037) skins and a proprietary adhesive.
Q: How thick is a stainless steel honeycomb panel?
A: The overall thickness of the stainless steel honeycomb panel is 20mm, and 12mm, and the length of the panel is 2440mm, 3050mm, and 3660 mm.
Q: What is the R value of a stainless steel honeycomb panel?
A: Honeycomb cores are great insulators, with R factor ratings ranging up to 5.5 per inch of thickness. Polypropylene's natural harmonic of 125Hz to 150Hz dampens sounds and vibrations.
Q: What is the density of a stainless steel honeycomb panel?
A: Honeycomb cores can be produced with densities of 60 – 120 kg/m³. Our standard honeycomb core has a density of 80-90 kg/m³ and has a compressive strength of 1. 2 MPa and a compressive modulus of 40 MPa.
Q: What are the properties of stainless steel honeycomb panels?
A: Aluminium honeycomb is lightweight, compression and shear resistant, has an excellent fire rating and is corrosion-resistant, non-rotting and recyclable. Aluminium honeycomb used as a panel core is the ideal answer when you need: lightness. stiffness.
Q: What is the thermal conductivity of a stainless steel honeycomb panel?
A: The main characteristics of the aggregates are relatively similar: density of 80–100 kg/m3, thermal conductivity of 0.042–0.045 W/m∙K, specific heat capacity of 1240–1330 J/g∙K, kinetic water absorption from 456–584%.
Kangbeier Technology Innovation (Shandong) Co., Ltd. is one of the most professional stainless steel honeycomb panel manufacturers and suppliers in China, specialized in providing high quality customized service. Be free to wholesale discount stainless steel honeycomb panel made in China here from our factory. For price consultation, contact us.
